Depositional Environment Analysis and the Relationship Between Sedimentary Facies and Diagenetic Processes in the upper deposits of the Dalan Formation, Central and Western Parts of the Qatar-Fars Arc
Subject Areas :L. Samadpour 1 , Hosein Mosaddegh 2 , B. Biranvandb 3 * , H. Rahimpour Bonab 4 , A. Yahyaei 5
1 - Associate Professor, Department of Geology, Faculty of Erath Sciences, Kharazmi University, Tehran
2 -
3 -
4 -
5 -
Keywords: Upper Dalan, Diagenesis, Microfacies, Depositional Environment.,
Abstract :
The Dalan Formation of upper Permian age, is considered one of the most significant reservoir rocks in the Zagros region and the Persian Gulf. In this study, facies characteristics and influential diagenetic factors affecting facies variations are investigated in three wells from three fields in the western Qatar-Fars Arc. Based on microfacies analysis of 252 thin sections, eleven microfacies were identified, including massive to layer anhydrite, fabric fenestral dolomudstone, stromatolite bindstone, dolomitic mudstone, bioturbation mudstone, bioclastic wackestone/ packstone with green algae and benthic foraminifera, ooid/ ploid packstone to grainstone, ooid grainstone, intraclast/ bioclastic grainstone, bioclastic/ intraclast wackestone to packstone and bioclastic mudstone. These microfacies represent environments ranging from upper intertidal zones, lagoon, shoal, open marine, to mid-ramp settings. The gradual transition of microfacies, absence of large barrier reef structures, lack of turbiditic deposits, and presence of skeletal allochems such as benthic foraminifera, green algae, bivalves, brachiopods, and echinoderms indicate deposition in a homoclinal carbonate ramp platform. The study's findings reveal that diagenetic processes, including micritization, cementation, dissolution, neomorphism, dolomitization, and physical and chemical compaction, are observed across the studied intervals. These diagenetic processes occurred in four different settings: marine, meteoric, burial, and uplift and influenced the sediments throughout the eogenetic, mesogenetic, and telogenetic stages. Cementation is primarily associated with low-energy, intertidal facies but also occurs within high-energy facies, such as bioclastic packstone or ooid grainstone, which are characteristic of lagoonal and shoal environments.
امرائی، ج.، رضایی، پ.، امینی، ع.، زمانزاده، س. م. و توکلی، و.، 1398. تحلیل ریزرخساره¬ها و پتروفاسیس¬ها، ویژگی¬های دیاژنتیکی و شرایط محیطی سازند فراقان در بخش مرکزی خلیج فارس، فصلنامه زمین‌شناسی ایران، 13(50)، 15-32.
آقانباتي، ع.، 1392. زمین‌شناسی ايران، انتشارات سازمان زمین‌شناسی و اکتشافات معدنی کشور،586.
سجادی، ف.، توکلی، و.، سفیداری، ا. و امامی نیری، م.، 1400. کاربرد توموگرافی نوع تخلخل در بازسازی تکامل مخازن کربناته، سازندهای کنگان و دالان در بخش مرکزی خلیج فارس، فصلنامه زمین‌شناسی ایران، 15(59)، 13-28.
سفیداری، ا.، امینی، ع.، یوسف¬پور، م. و زمانزاده، س. م.، 1397. تعیین نقش محیط رسوبی و فرایندهای دیاژنزی در کیفیت مخزنی بخش بالایی سازند سورمه در میدان سلمان، فصلنامه زمین‌شناسی ایران، 11(45)، 119-136.
Aali, J., Rahimpour-Bonab, H. and Kamali, M.R., 2006. Geochemistry and origin of the world's largest gas field from Persian Gulf, Iran, Journal of Petroleum Science and Engineering, 50(3-4),161-175.
Abdolmaleki, J., Tavakoli, V. and Asadi-Eskandar, A., 2016. Sedimentological and diagenetic controls on reservoir properties in the Permian–Triassic successions of western Persian Gulf, southern Iran, Journal of Petroleum Science and Engineering, 141,90-113.
Alavi, M., 2007. Structures of the Zagros fold-thrust belt in Iran, American Journal of Science, 307(9), 1064-1095.
Amel, H., Jafarian, A., Husinec, A., Koeshidayatullah, A. and Swennen, R., 2015. Microfacies, depositional environment and diagenetic evolution controls on the reservoir quality of the Permian Upper Dalan Formation, Kish Gas Field. Journal of Marine and Petroleum Geology, 67: 57–71.
Angiolini, L., Balini, M., Garzanti, E., Nicora, A., Tintori, A., Crasqiun, S. and Muttoni, G., 2003. Permian climatic and paleogeographic changes in Northern Gondwana: the Khuff Formation of Interior Oman, Palaeogeography, Palaeoclimatology, Palaeoecology, 191, 269-300.
Bathurst R. G. C., 1975. Carbonate Sediments and their Diagenesis, 2nd edn., Developments in Sedimentology No. 12. Elsevier, Amsterdam, 658.
Büyükutku, A. G., 2009. Reservoir properties of Karaisalı formation in the Adana Basin, Southern Turkey. Journal of Petroleum Science and Engineering, 65(1-2), 33-44.
Dickson, J. A. D., 1965. A modified staining technique for carbonates in thin section: Nature, 205, 587.
Dunham¬¬¬, R.J., 1962. Classification of carbonate rocks according to depositional texture. American Association of Petroleum Geologists Memoir1. 108–121.
Embry, A.F. and Klovan, J.E., 1971. A Late Devonian reef tract on northeastern Banks Island, NWT. Bulletin of Canadian Petroleum Geology, 19(4),730-781.
Enayati–Bidgoli, A.H. and Rahimpour–Bonab, H., 2016. A geological based reservoir zonation scheme in a sequence stratigraphic framework: A case study from the Permo–Triassic gas reservoirs, Offshore Iran, Marine and Petroleum Geology, 73,36-58.
Esrafili– Dizaji, B. and Rahimpour–Bonab, H., 2013. A review of Permo–Triassic reservoir rocks in the Zagros Area, Sw Iran: Influence of the Qatar–Fars Arch, Journal of Petroleum Geology, 36(3),257-279.
Flügel, E., 2010. Microfacies of Carbonate Rocks: Analysis, Interpretation and Application, Springer. Berlin. Heidelberg. New York. 976.
Insalaco, E., Virgone, A., Courme, B., Gaillot, J., Kamali, M., Moallemi, A., Lotfpour, M. and Monibi, S., 2006. Upper Dalan Member and Kangan Formation between the Zagros Mountains and offshore Fars, Iran: depositional system, biostratigraphy and stratigraphic architecture. GeoArabia, 11(2),75-176.
Jafarian, A., Javanbakht, M., Koeshidayatullah, A., Pimentel, N., Salad Hersi, O., Yahyaei, A. and Beigi, M., 2017. Paleo environmental, diagenetic, and eustatic controls on the Permo– Triassic carbonate–evaporite reservoir quality, Upper Dalan and Kangan formations, Lavan Gas Field, Zagros Basin. Journal of Geological, 53: 1442-1457.
Kakemem, U., Ghasemi, M., Adabi, M. H., Husinec, A., Mahmoudi, A. and Anderskouv, K., 2023. Sedimentology and sequence stratigraphy of automated hydraulic flow units-The Permian Upper Dalan Formation, Persian Gulf, Marine and petroleum geology 147:105965.
Konert, G., Afifi, A.M., Al-Hajri, S.I.A. and Droste, H.J., 2001. Paleozoic stratigraphy and hydrocarbon habitat of the Arabian Plate, GeoArabia, 6(3), 407-442.
Lucia, F.J., 2007. Limestone reservoirs. Carbonate Reservoir Characterization: An Integrated Approach,181-215.
Machel, H. G., 2005. Investigations of burial diagenesis in carbonate hydrocarbon reservoir rocks. Geoscience Canada, 32(3), 103-128.
Marenco, P. J., Corsetti, F. A., Hammond, D. E., Kaufman, A. J. and Bottjer, D. J., 2008. Oxidation of pyrite during extraction of carbonate associated sulfate. Chemical Geology, 247(1-2), 124-132.
Mehrabi, H., Mansouri, M., Rahimpour-Bonab, H., Tavakoli, V. and Hassanzadeh, M., 2016. Chemical compaction features as potential barriers in the Permian-Triassic reservoirs of Southern Iran, Journal of Petroleum Science and Engineering, 145, 95-113.
Mehrabi, H., Rahimpour-Bonab, H., Enayati-Bidgoli, A. H. and Esrafili-Dizaji, B., 2015. Impact of contrasting paleoclimate on carbonate reservoir architecture: Cases from arid Permo-Triassic and humid Cretaceous platforms in the south and southwestern Iran. Journal of Petroleum Science and Engineering, 126, 262-283.
Moore, C. H. and Wade, W. J., 2013. Carbonate reservoirs: Porosity and diagenesis in a sequence stratigraphic framework, Developments in Sedimentology. Elsevier New York, 67, 347.
Moore, G., 2001. Corporate social and financial performance: An investigation in the UK supermarket industry. Journal of Business ethics, 34, 299-315.
Moradi, M., Kadkhodaie, A., Rahimpour-Bonab, H. and Kadkhodaie, R., 2024. Integrated reservoir characterization of the Permo-Triassic gas reservoirs in the Central Persian Gulf. Petroleum.
Philip, J. M. and Gari, J., 2005. Late Cretaceous heterozoan carbonates: Palaeoenvironmental setting, relationships with rudist carbonates (Provence, south-east France). Sedimentary Geology, 175(1-4), 315-337.
Pomar, L., Brandano, M. and Westphal, H., 2004. Environmental factors influencing skeletal grain sediment associations: a critical review of Miocene examples from the western Mediterranean. Sedimentology, 51(3), 627-651.
Rahimpour-Bonab, H., 2007. A procedure for appraisal of a hydrocarbon reservoir continuity and quantification of its heterogeneity. Journal of Petroleum Science and Engineering, 58(1), 1-12.
Rezavand, N., Jahani, D. and Asilian, H., 2017. Facies, Depositional Environment and Sequence Stratigraphy of Dalan Formation in Persian Gulf (Qatar-South Fars Arch) Well SP-A Subsurface Section. Journal of Science and Technology, 10(34): 1-16.
Scholle, P.A. and Ulmer-Scholle, D.S., 2003. A color guide to the petrography of carbonate rocks: grains, textures, porosity, diagenesis, AAPG Memoir 77(77).
Seibel, M. J. and James, N. P., 2017. Diagenesis of Miocene, incised valley-filling limestones; Provence, Southern France. Sedimentary Geology, 347, 21-35.
Sharland, P.R., Archer, R., Casey, D.M., Davies, R.B., Hall, S.H., Heward, A.P., Horbury, A.D. and Simmons, M.D., 2001. Arabian Plate sequence stratigraphy. GeoArabia Special Publication, vol. 2. Gulf PetroLink, Bahrain. 371.
Szabo, F. and Kheradpir, A., 1978. Permian and Triassic stratigraphy, Zagros basin, south-west Iran, Journal of Petroleum Geology, 1(2),57-82.
Tavakoli, V. and Barfizadeh, H., 2024. The Role of Plate Movements on Reservoir Development of the Iranian Carbonate Formations: A Review of the Interplay Between Tectonics, Paleoclimate, and Diagenesis. Results in Earth Sciences, 100037.
Tavakoli, V., Naderi-Khujin, M. and Seyedmehdi, Z., 2018. The end-Permian regression in the western Tethys: sedimentological and geochemical evidence from offshore the Persian Gulf, Iran. Geo-Marine Letters, 38, 179-192.
Tucker, M. E. and Wright, V. P., 2009. Carbonate sedimentology. John Wiley & Sons.Tucker, M. E., 1991. Sequence stratigraphy of carbonate-evaporite basins: models and application to the Upper Permian (Zechstein) of northeast England and adjoining North Sea. Journal of the Geological Society, 148(6), 1019-1036.
Warren, J. K., 2006. Evaporites: sediments, resources and hydrocarbons: Springer Verlag, Brunei, 1035.
Wilson, J.L., 1975. Principles of carbonate sedimentation, Carbonate Facies in Geologic History,1-19.
Zeigler, M.A. and Martin, A.Z., 2001. Late Permian to Holocene paleofacies evolution of the Arabian Plate and its hydrocarbon occurrences. GeoArabia, 6(3), 445-504.
